| Mode | ZGD-12G | ZGD-25G | ZGD-50G | ZGD-75G | ZGD-100G | ZGD-150G | ZGD-200G | ZGD-300G |
| Capacity | 12KG | 25KG | 50KG | 75KG | 100KG | 150KG | 200KG | 300KG |
| Power supply | 1AC/N/PE/220V/50HZ | 1AC/N/PE/220V/50HZ | 3AC/N/PE/380V/50HZ | 3AC/N/PE/380V/50HZ | 3AC/N/PE/380V/50HZ | 3AC/N/PE/380V/50HZ | 3AC/N/PE/380V/50HZ | 3AC/N/PE/380V/50HZ |
| Total power | 1.87KW | 3.6KW | 4.65KW | 5.15KW | 6.7KW | 9.2KW | 12.3KW | 15.3KW |
| Equipment current | 8.5 | 16 | 7 | 9 | 12 | 15 | 18 | 23 |
| Tube power | 220V/1.8KW | 220V/3.5KW | 380V/4.5KW | 380V/5KW | 380V/6.5KW | 380V/9KW | 380V/12KW | 380V/15KW |
| Fan power | 220V/50HZ/75W | 220V/50HZ/135W | 220V/50HZ/155W | 220V/50HZ/155W | 220V/50HZ/215W | 220V/50HZ/215W | 380V/50HZ/320W | 380V/50HZ/320W |
| Fan flange | 100MM | 120MM | 120MM | 120MM | 143MM | 150MM | 190MM | 190MM |
| Base dimensions | 108*108 | 148*148 | 158*158 | 158*158 | 178*178 | 200*200 | 230*230 | 230*230 |
| Safety device | Power off and alarm after over-temperature | |||||||
| Wooden frame size（mm） | 69*43*70 | 76*46*83 | 85*49*95 | 89*55*104 | 102*63*109 | 107*67*129 | 120*83*143 | 129*94*160 |
| Equipment weight | 34KG | 40KG | 40KG | 46KG | 60KG | 80KG | 100KG | 140KG |
The equipment features a curved design for the hot air pipes, which prevents powder accumulation at the bottom of electric heating pipes and reduces the risk of combustion.
The equipment adopts a high-performance hot air diffusion device that uniformly and evenly distributes hot air to maintain a consistent drying temperature for plastic materials, ultimately improving drying efficiency.This product has several nble features, including rapid and uniform heating with precise control, as well as a built-in over-temperature protection system for safety and reliability. Additionally, it can be used in conjunction with accessories such as a timer, hot air recirculation, and a stand to enhance flexibility andota convenience. Overall, this product is an efficient, precise, safe, and versatile heating device that can quickly and uniformly heat materials while ensuring user safety and satisfaction through its various features and accessories.
The equipment features a curved design for the hot air pipes, which prevents powder accumulation at the bottom of electric heating pipes and reduces the risk of combustion.The equipment comes equipped with a demagnetization and over-temperature protection function that automatically cuts off the main power supply when the drying temperature exceeds the preset deviation value, ensuring safe operation.
